Section 10: Instrument programming Series 3700A System Switch/Multimeter Reference Manual
10-34 3700AS-901-01 Rev. D/June 2018
Keithley has created a collection of remote commands specifically for use with Keithley TSP-enabled
instruments; for detailed information about those commands, refer to the Command reference (on
page 11-1). You can build scripts from a combination of these commands and Lua programming
statements. Scripts that you create are referred to as "user scripts." Also, some TSP-enabled
instruments include built-in factory scripts.
The following figure shows an example of the Test Script Builder. As shown, the workspace is divided
into these areas:
• Project navigator
• Script editor
• Outline view
• Programming interaction
• Help files
Figure 120: Example of the Test Script Builder workspace
Item
Description
1
Project navigator
2
Script editor; right-click to run the script that is displayed
3
Outline view
4
Programming interaction
5
Help; includes detailed information on using Test Script Builder
