Series 3700A System Switch/Multimeter Reference Manual Section 11: TSP command reference
3700AS-901-01 Rev. D/June 2018 11-337
Set eventID to one of the existing trigger event IDs shown in the following table.
Trigger event IDs
Trigger event ID
Description
channel.trigger[N].EVENT_ID or 41 to 48
The trigger event generated by the channel trigger N.
digio.trigger[N].EVENT_ID or 1 to 14
An edge (either rising, falling, or either based on the
configuration of the line) on the digital input line.
display.trigger.EVENT_ID or 39
The trigger key (TRIG) on the front panel is pressed.
dmm.trigger.EVENT_LIMIT1_HIGH or 53
A DMM trigger event that indicates a measurement has
exceeded the high limit value on limit 1.
dmm.trigger.EVENT_LIMIT1_LOW or 52
A DMM trigger event that indicates a measurement has
exceeded the low limit value on limit 1.
dmm.trigger.EVENT_LIMIT2_HIGH or 55
A DMM trigger event that indicates a measurement has
exceeded the high limit value on limit 2.
dmm.trigger.EVENT_LIMIT2_LOW or 54
A DMM trigger event that indicates a measurement has
exceeded the low limit value on limit 2.
trigger.EVENT_ID or 40
A *trg message on the active command interface. If
GPIB is the active command interface, a GET message
also generates this event.
trigger.blender[N].EVENT_ID or 58 to 59
A combination of events has occurred.
trigger.timer[N].EVENT_ID or 20 to 23
A delay expired.
tsplink.trigger[N].EVENT_ID or 17 to 19
An edge (either rising, falling, or either based on the
configuration of the line) on the TSP-Link trigger line.
lan.trigger[N].EVENT_ID or 29 to 36
A LAN trigger event has occurred.
scan.trigger.EVENT_SCAN_READY or 24
Scan ready event.
scan.trigger.EVENT_SCAN_START or 25
Scan start event.
scan.trigger.EVENT_CHANNEL_READY or 28
Channel ready event.
scan.trigger.EVENT_MEASURE_COMP or 56
Measure complete event.
scan.trigger.EVENT_SEQUENCE_COMP or 50
Sequence complete event.
scan.trigger.EVENT_SCAN_COMP or 26
Scan complete event.
scan.trigger.EVENT_IDLE or 27
Idle event.
schedule.alarm[N].EVENT_ID or 37 to 38
Trigger event generated by the alarm N.
Use one of the text trigger event IDs (for example, digio.trigger[N].EVENT_ID) to set the
stimulus value rather than the numeric value. Doing this will make the code compatible for future
upgrades.
Example
scan.trigger.sequence.stimulus = scan.trigger.EVENT_CHANNEL_READY
Sets the trigger stimulus of the sequence event detector to the channel ready event.
Also see
scan.trigger.measure.stimulus (on page 11-334)
Scanning and triggering (on page 5-23)
