Series 3700A System Switch/Multimeter Reference Manual Section 3: Instrument description

3700AS-901-01 Rev. D/June 2018 3-23

Front-panel

channel setting

Symbol

Definition

Symbol meaning

Channel label

XXXXXX

First 6 characters of label

Used with single letter

symbols

XXXXXXXXXXXX

First 12 characters of label

Used with the non-single

letter symbols

Digital I/O mode

settings

DIG IN

Digital input mode

Used with 12-character label

or no label

DIG OUT

Digital output mode

Used with 12-character label

or no label

DIG pOUT

Digital output protected mode

Used with 12 character label

or no label

I (uppercase

"i")

Digital input mode

Used with 6-character label

Digital output mode

Used with 6-character label

Digital output protected mode

Used with 6-character label

Totalizer mode

settings

Rise Ed

Totalizer rising edge mode

Used with 12-character label

or no label

Fall Ed

Totalizer falling edge mode

Used with 12-character label

or no label

Rise-TTL

Totalizer rising edge TTL level

mode

Used with 12-character label

or no label

Fall-TTL

Totalizer falling edge TTL level

mode

Used with 12-character label

or no label

Rise-RST

Totalizer rising edge read reset

mode

Used with 12-character label

or no label

Fall-RST

Totalizer falling edge read reset

mode

Used with 12-character label

or no label

RiseTRST

Totalizer rising edge TTL read

reset mode

Used with 12-character label

or no label

FallTRST

Totalizer falling edge TTL read

reset mode

Used with 12-character label

or no label

Totalizer rising edge mode

Used with 6-character label

Totalizer falling edge mode

Used with 6-character label

DAC mode settings

Voltage function mode

Used with 6-character label

I (uppercase

"i")

Current function either 1 or 2

mode

Used with 6-character label

Voltage function 1 mode

Used with 12-character label

or no label

Current function 1 mode

Used with 12-character label

or no label

Current function 2 mode

Used with 12-character label

or no label

pV1

Protected voltage function 1 mode

Used with 12-character label

or no label

pI1

Protected current function 1 mode

Used with 12-character label

or no label

pI2

Protected current function 2 mode

Used with 12-character label

or no label

DAC output enable

settings

Off

Output enable is disabled

Used with 6 or 12 character

label

Output enable is enabled

Used with 6 or 12 character

label
