7½ Digit Graphical Sampling Multimeter Calibration Manual Section 2: Pe
rformance verification
DMM7510-905-01 Rev. A / April 2015 2-47
Verify DC current 10 µA and 100 µA range
Characterized shunt (Ω): 1.9607843E+05
Range Nominal
input
Calibrator
setpoint
(V)
Shunt
measure-
ment
(V)
Calculated input
(A)
Lower limit
(A)
Upper limit
(A)
Ref DMM
Zero
0.00E+00 0 8.00E-07 0 n/a n/a
1.00E-05
0
STANDBY
n/a
n/a
-3.00E-10
3.00E-10
0.00001
1.9707843
1.9607843
1.0000000E-05
9.9989500E-06
1.0001050E-05
0.000005
0.9853921
0.9803922
5.0000003E-06
4.9993253E-06
5.0006753E-06
-0.000005
-1.9707843
-0.9803922
-5.0000003E-06
-5.0006753E-06
-4.9993253E-06
-0.00001
-1.9707843
-1.9607843
-1.0000000E-05
-1.0001050E-05
-9.9989500E-06
Ref DMM
Zero
0.00E+00 0 V 8.00E-07 0 n/a n/a
1.00E-04
0
n/a
-9.00E-10
9.00E-10
0.0001
19.617843
19.607843
1.0000000E-04
9.9994000E-05
1.0000600E-04
0.00005
9.8089216
9.8039216
5.0000001E-05
4.9997001E-05
5.0003001E-05
-0.00005
-9.8089216
-9.8039216
-5.0000001E-05
-5.0003001E-05
-4.9997001E-05
-0.0001
-19.617843
-19.607843
-1.0000000E-04
-1.0000600E-04
-9.9994000E-05
