Keithley SourceMeter 2612 User Manual

Series 2600 System SourceMeters User’s Manual Test Script Processor Interaction 3-7
Return to In this section: 2600S-900-01 Rev. A / May 2006
Figure 3-2
Importing a factory script project from the Series 2600
A) Click File to display the drop-down file menu
and click Import to open the Import wizard.
B) In the Import Select box, click Existing Project
From Instrument and then click Next.
C) In the Import Project From Instrument box, click
the KIGeneral project, and then click Finish.
KIGeneral
KIGeneral

Keithley SourceMeter 2612 Specifications

General

Model	2612
Type	SourceMeter
Channels	2
Measurement Resolution	6.5 digits
Power Output	100 W
Current Source Range	±3 A
Maximum Power	100W
Voltage Measurement Resolution	100 nV (6.5 digits)
Current Measurement Resolution	10pA
Interface	GPIB, USB, Ethernet
