Kemppi Kempact Pulse 3000 Operation Instructions

10 – Kempact pulse 3000, Kempactcool 10 / 0813 © Kemppi oy
2.12. COOLING UNIT (KEMPACTCOOL 10)
Cooling liquid is injurious! Avoid also contact with skin or eyes. In case of injury,
seek for medical advice.
Cooling unit KempactCool 10 together with MIG-gun of Kemppi's PMT-W and MMT-W range
enables MIG welding with water-cooled gun.
The cooling unit is installed beneath the power source with screws and mounting plate. Electrical
connections are on the bottom of power source. Fill the reservoir with a 20 - 40 % mixture of etanol
and water, or with any other suitable antifreeze. The capacity of the reservoir is 3 litres.
Only an authorised electrician is allowed
to install electrical connection!
The bottom of power source
1. 400 V
2. Control connector
3. Equipment earth
Installation of cooling unit:
Electrical connection
for the cooling unit:
Filling the reservoir:
