Kemppi Kempact Pulse 3000 Operation Instructions

Kempact pulse 3000, Kempactcool 10 / 0813 – 13© Kemppi oy
3.3.3. Selecting 1-mig/pulse mig synergy curves
The program number of the synergy curve is selected using the plus-minus buttons and is displayed
on "SYNERGIC PRG".
The middle display is actual material group display (eg. SS, AL, CUS, FE, GEN). Wire diameter
(mm) can be seen on the right side. This information will only be displayed for a while.
The “PRG INFO” button gives more curve information:
One press will revert to the material group and diameter display, a second will display the type
number of the material and a third run through the gas consistency components one by one.
KEMPACT PULSE 3000 Synergic programs
1-MIG Pulse Double
Pulse
Wire, ø Material Gas Wire Feed
Range
00 All All All 1,0 - 18,0
01 All All All 0,5 - 18,0
SS-group
S1 S1 S1
0,8 mm SS 308 / 316 Ar + 2 % CO
²
S2 S2 S2
0,9 mm SS 308 / 316 Ar + 2 % CO
²
S3 S3 S3
1,0 mm SS 308 / 316 Ar + 2 % CO
²
S4 S4 S4
1,2 mm SS 308 / 316 Ar + 2 % CO
²
S5
0,9 mm SS 316 FC Ar + 18 % CO
²
S7
1,2 mm SS 316 FC Ar + 18 % CO
²
Al-group
A1 A1 A1 1,0 mm AlMg5 / AlMg4,5Mn Ar
A2 A2 A2 1,2 mm AlMg5 / AlMg4,5Mn Ar
A6 A6 A6 1,0 mm AlSi5 / AlSi12 Ar
A7 A7 A7 1,2 mm AlSi5 / AlSi12 Ar
Cu-group
C1 C1 C1 0,8 mm CuSi3 Ar
C2 C2 C2 0,9 mm CuSi3 Ar
C3 C3 C3 1,0 mm CuSi3 Ar
C4 C4 C4 1,2 mm CuSi3 Ar
C5 C5 C5 0,8 mm CuAl8 Ar
C6 C6 C6 0,9 mm CuAl8 Ar
C7 C7 C7 1,0 mm CuAl8 Ar
C8 C8 C8 1,2 mm CuAl8 Ar
Fe-group
F1 F1 F1 0,8 mm Fe Ar + 18 % CO
²
F2 F2 F2 0,9 mm Fe Ar + 18 % CO
²
F3 F3 F3 1,0 mm Fe Ar + 18 % CO
²
F4 F4 F4 1,2 mm Fe Ar + 18 % CO
²
