22 – Kempact pulse 3000, Kempactcool 10 / 0813 © Kemppi oy
Kempact Pulse 3000
Mains connection 3~400V +/-15%, 50/60Hz
Connected load
40% ED 12 kVA 250A
60% ED 10 kVA 207A
100% ED 7,5 kVA 160A
Mains cable/fuse 4x1,5 mm² - 5 m/16A delayed
Load capacity
40% ED 250A /26,5V
60% ED 207A /24V
100% ED 160A /22V
Adjustment range 8 - 30V
Wire feed speed
1 - 18 m/min
Open circuit voltage 56 V
Power ratio 0,69 (250A / 26V)
Efciency 0,84 (250A / 26V)
Filler wires
Fe, Ss
0,6 ... 1,2 mm
Cored wire 0,9 ... 1,2 mm
Al 0,9 ... 1,2 mm
CuSi
0.8 ... 1,2 mm
Shielding gas CO
²
, Ar, Ar & CO
²
mixed gases
Wire spool diameter
300 mm (15 kg)
Feed roll Ø 32 mm
Thermal class H (180 °C) / B (130 °C)
Dimensions
length 580 mm
width 280 mm
height 440 mm
Weight
22 kg
Gun connector EURO
Principle of operation 4-wheel feed
Cooling unit KempactCool 10
Connection voltage 400 V - 15 % ... 10 %
Connection capacity 250 W
Cooling power 1 kW
Start pressure, max 4,5 bar
Cooling liquid 20 % - 40 % etanol/water
Reservoir volume n. 3 l
External dimensions length 580 mm
width 280 mm
height 300 mm
Weight
13 kg
Kempact Pulse 3000 and Cooling unit KempactCool 10
Range of temperature for use - 20 °C ...+ 40 °C
Storage temperature for use - 40 °C ...+ 60 °C
Degree of protection IP23C
The products meet conmormity reguirements for CE marking.
Cooling unit KempactCool 10
Connection voltage 400 V - 15 % ... 10 %
Connection capacity 250 W
Cooling power 1 kW
Start pressure, max 4,5 bar
Cooling liquid 20 % - 40 % glycol-water
Reservoir volume n. 3 l
External dimensions length 580 mm
width 280 mm
height 300 mm
Weight
13 kg
Range of temperature for use - 20 °C ...+ 40 °C
Storage temperature for use - 40 °C ...+ 60 °C
Degree of protection IP23C
6. TECHNICAL DATA

Kemppi Kempact Pulse 3000 Specifications

General

Brand	Kemppi
Model	Kempact Pulse 3000
Category	Welding System
Language	English
