SETUP-functions
Error codes
Err 3
Net overvoltage
Err 4
Power source overheated
Err 5
Cooling unit has stopped welding
Err 6
Power source output voltage is has risen > 80 Vdc
Err 153
PMT-gun overheated or RMT 10 installed and PMT-gun in FU-position. In some cases this error may
be presented if one of the main supply voltage phases are missing.
Err 154
Wf-motor overload (current > 4,5 A/ 5 s.)
6
Parameter selection
Parameter adjustment
10 s.
The SETUP is entered by pressing the setup-button for 10 seconds.
Adjustable parameter
Post gas time
Pre gas time
Hot Start level
2T Hot Start duration
Crater fill end level
Crater fill time (angle)
Creep start starting level
Creep start time (angle)
Doublepulse freq.
Double pulse Wf-speed amplitude
Ignition pulse
Pulse top current
Post current time
Arc length adj. range
Calibration
Maximum wf-speed
Liquid cooled gun PTC
Gun controller automatic detection
Display recovery delay
Number Display
Syn
Adj. range Quantity
1
2
11
12
14
15
17
18
21
22
31
33
35
41
42
51
53
54
81
99 Factory settings recall
PoG
PrG
Hot
H2t
CFL
CFS
CSL
CSS
dFr
DA
StP
PuC
PoC
ALr
CAl
FS
Gun
GrE
dIS
FAC
Factory setting
Syn
30
2.0
30
1
Syn
0
Syn
Syn
0
0
Syn
0
0
18
On
On
5.0
OFF
0.0…9.9
0.0…9.9
-50…+75
0.1…9.9
10…90
1…20
10…90
0.1…5
0.0…8.0
0.0…3.0
-9…0…+9
-10…+15
0.0…10
-50…+75
1.0
18 tai 25
On/Off
On/Off
1.0…20
Off/Pan/All
s
s
%
s
%
s/10m/min
%
Hz
s/10m/min
m/min
%
s
%
V/100A
m/min
s
Err 253
Wrong welding process
To Next Page
