General
The machine may be repaired only by an authorized and licensed technician or workshop!
First do a visual check to find the possible loose connectors, broken wires or signs of overheating
Troubleshooting diagram
PROBLEM POSSIBLE CAUSE REMEDY
Power source doesn´t start Net fuses or supply cable. Check the net fuses and supply cable
condition.
Power source can´t provide full
power.
Net fuses or supply cable.
Main transformer T001 or
secondary siode card Z002.
Check the net fuses and supply cable
condition.
Check the main transformer T001´s
ferrites and secondary diode card
diodes.
