10. TECHNICAL DATA
Kempomat 2500
Rated voltage
230 V / 400 V
Connection voltage
3~ 400 V 380 V -10% ... 415 V +6%
3~ 230 V 220 V -10% ... 240 V +6%
Rated power at max. current 230 V / 400 V
30 % ED 9,2 kVA
60 % ED 5,9 kVA
100 % ED 4,0 kVA
Load capacity 40 °C (nominal values)
30 % ED 250 A/26 V
60 % ED 180 A/23 V
100 % ED 140 A/21 V
Control range
40 – 250 A/14 – 26 V
Voltage steps
10 steps
Open circuit voltage max.
35 V
Efficiency at max. current
250 A/26 V 75 %
Power factor at max. current
250 A/26 V 0,95
Fuse, delayed
8 A
Wire feed mechanism
2 wire feed
Diameter of feed roll
32 mm
Wire feed speed
I 0 – 18 m / min
II 0 – 25 m / min
Filler wires
ø Fe, Ss 0,6 – 1,2 mm
ø Cored wire 0,8 – 1,2 mm
ø Al 1,0 – 1,2 mm
Wire spool
max. weight 20 kg
max. size ø 300 mm
Gun connector
Euro
Temperature class
H (180 °C)
Operating temperature range
-20 ... +40 °C
Storage temperature range
-40 ... +60 °C
Degree of protection
IP23S
EMC class
A
External dimensions
LxWxH 930 x 440 x 860 mm
Weight
80 kg
21
Kempomat 2500, 3200, 4200 / © Kemppi Oy / 1117
