Kenwood NX-5200 Service Manual

1-12 (No.RA018<Rev.002>)
• Direct enter mode
*1: F3,K3,E types only
Key\Item RX
Frequency
TX
Frequency
RX
Signaling
TX
Signaling
RX
RAN
TX
RAN
RX
NAC
TX
NAC
Channel
Name
[ ] Decision Character/Channel name decision
[ ] Delete
[ ] Unused
[ ] Exit panel program mode
[] Unused Character selection (upper case char-
acter → lower-case character → digit
→ upper case character...)
[] Character selection (upper case char-
acter → lower-case character → digit
→ upper case character...)
[] Move a cursor to the right
[] Move a cursor to the left
Keypad
[0] ~ [9] *1
Add a digit to the current number
Keypad
[*] *1
Decision Input character switching
Keypad
[#] *1
Delete/Back to the previous item Delete
