Kenwood NX-5200 Service Manual

(No.RA018<Rev.002>)1-39
*2: Wide4K can be set up only when the PC test mode is used.
*3: When P25 Phase1 is selected, in C4FM and LSM, there is an adjustment item, respectively.
13 NXDN High
Deviation
NDEV- - - - --55Transmitter
Section 10
1~1024
14 QT Deviation QT - 5 5 *2 5 - - - - Transmitter
Section 11
1~1024
15 DQT Deviation DQT - 5 5 *2 5 - - - - Transmitter
Section 12
1~1024
16 LTR Deviation LTR - 5 5 *2 5 - - - - Transmitter
Section 13
1~1024
17 DTMF Deviation DTMF - 5 5 *2 5 - - - - Transmitter
Section 14
1~1024
18 Single Tone
Deviation
TONE - 5 5 *2 5 - - - - Transmitter
Section 15
1~1024
19 MSK Deviation MSK - 5 5 *2 5 - - - - Transmitter
Section 16
1~1024
20 CW ID Deviation CWID - - - 5 - - - - Transmitter
Section 17
1~1024
21 Battery Warning
Level
BATT (BATT
measurement value)
1point ADJ Transmitter
Section 18
1~256
22 Internal
Microphone Gain
INMIC - - -
-
----Transmitter
Section 20
-250~250
23 Sensitivity 1 SENS1 (RSSI measurement
value)
- - 5----Receiver
Section 2
1~256
24 Sensitivity 2 SENS2 (RSSI measurement
value)
- - 5----Receiver
Section 3
1~256
25 RSSI Reference RRSSI (RSSI measurement
value)
- - 5----Receiver
Section 4
1~256
26 Open Squelch SQL (ASQDET
measurement value)
5 5 *2 5 5 *3 - 5 5 Receiver
Section 5
1~256
27 Low RSSI LRSSI (RSSI measurement
value)
- - 5----Receiver
Section 6
1~256
28 High RSSI HRSSI (RSSI measurement
value)
- - 5----Receiver
Section 7
1~256
29 Tight Squelch SQLT (ASQDET
measurement value)
5 5 *25----Receiver
Section 8
1~256
Order Adjusutment
item
Main
LCD
display
Sub LCD
display
Aw
(Analog
Wide)
As *2
(Analog
Wide 4k)
An
(Analog
Narrow)
P1
(P25
Phase1)
P2
(P25
Phase2)
Nn
(NXDN
Nar-
row)
Nv
(NXDN
Very
Nar-
row)
Adjust
item
Number
Adjustment range

Kenwood NX-5200 Specifications

General

IP Rating	IP67
Zones	128
GPS	Yes
Bluetooth	Yes
Voltage Range	7.5V DC ±20%
Operating Temperature	-30°C to +60°C
Frequency Range	136-174 MHz
Battery Life	14 hours (Digital mode)
Digital Protocol	NXDN, DMR
Display	LCD
