(No.RA018<Rev.002>)1-65
4.13.2 Key operation
4.13.3 5 or 9 reference level adjustments frequency
High Transmit Power, Medium Transmit Power, Low Trans-
mit Power, Balance, Maximum Deviation , P25 High Devia-
tion, P25 H-CPM Deviation, NXDN High Deviation, QT
Deviation, DQT Deviation, LTR Deviation, DTMF Deviation,
Single Tone Deviation, MSK Deviation, CW ID Deviation,
Sensitivity 1, Sensitivity 2, RSSI Reference, Open Squelch,
Low RSSI, High RSSI, Tight Squelch
Receive Assist, Transmit Assist
4.13.4 Adjustment item supplement
Key Function
Push Hold (1 second)
[Selector] -
[ ] Adjustment value up Continuation up
[ ] Adjustment value down Continuation down
[ ] Auto adjustment start -
[ ] Wide 5k/Wide 4k/
Narrow/P25/NXDN
-
[ Side1 ] -
[ Side2 ] -
[ Side3 ] -
[ ] Shift to panel test mode -
[ ] To enter 5,9 or 17 refer-
ence level adjustments
-
[ ] Writes the adjustment
value
-
[ ] Go to next adjustment
item
Back to last adjustment
item (At the time of 5, 9 or
17 point adjustment: Ad-
justment point change)
[AUX
(Orange)]
Output tone pattern
change of balance ad-
justment (A change is
possible only during bal-
ance adjustment.)
-
[PTT] Transmit
[0] to [9]
and
[#],[ ]
-
Tuning point Display RX (MHz) TX (MHz)
1 Low 1 136.05000 136.10000
2 Low 3 145.55000 145.60000
3 Center 2 155.05000 155.10000
4 High 1 164.55000 164.60000
5 High 3 173.95000 173.90000
Tuning point Display RX (MHz) TX (MHz)
1 Low 1 136.05000 136.10000
2 Low 2 140.80000 140.85000
3 Low 3 145.55000 145.60000
4 Center 1 150.30000 150.35000
5 Center 2 155.05000 155.10000
6 Center 3 159.80000 159.85000
7 High 1 164.55000 164.60000
8 High 2 169.30000 169.35000
9 High 3 173.95000 173.90000
Adjustment Item Description
Receive Assist The lock voltage of VCO (Receive) is ad-
justed.
This item must be adjusted before all ad-
justment items for receiver section are
adjusted.
Transmit Assist The lock voltage of VCO (Transmit) is ad-
justed.
This item must be adjusted before all ad-
justment items for transmitter section are
adjusted.
Frequency Frequency is adjusted under receiving
condition with SSG.
The SSG needs 0.003ppm accuracy so
please use a standard oscillator if neces-
sary.
This item can be adjusted only in PC Test
Mode so that the adjustment value is not
changed easily.
Ramp Offset Adjust this item to the optimal Ramp volt-
age.
High Transmit
Power
High Transmit Power is adjusted.
Medium Transmit
Power
Medium Transmit Power is adjusted.
Low Transmit
Power
Low Transmit Power is adjusted.
Balance The transmit modulation frequency re-
sponse is adjusted.
This item is adjusted so that the deviation
of 2kHz becomes the same deviation of
20Hz.
This item must be adjusted before all ad-
justment items for deviations are adjust-
ed.
Maximum Deviation
(P25/NXDN)
Maximum Deviation of P25/NXDN is ad-
justed.
Maximum Deviation
(Analog Wide 5K/
Wide 4K/Narrow)
Maximum Deviation of Analog (Wide 5K/
Wide 4K/Narrow) is adjusted.
This item must be adjusted before all ad-
justment items for tone deviations are ad-
justed.
QT Deviation QT deviation is adjusted.
