ES749 Flow Computer
56
FLOW INPUT
6.8
FLOW INPUT
(Continued)
Set the low scale value for the analog input signal.
The value entered here must be identical to the value set for the
owmeter.
Note:
• For owmeters with analog/linear output, the ow computer uses
the selected system units for volumetric owrate.
• The units for differential pressure owmeters are dependent on
the system units selected for pressure:
- Imperial units [inches H2O]
- Metric units: [mbar]
Input:
Number with oating decimal point: 0.000...999999
Display: .000 ft3/h
LOW SCALE VALUE
Set the full scale value for the analog input signal.
The value entered here must be identical to the value set for the
owmeter.
Note:
• For owmeters with analog/linear output, Target, generic
square law and Gilo owmeters, the ow computer uses
the selected system units for volumetric owrate.
• The units for differential pressure owmeters are
dependent on the system units selected for pressure:
- Imperial units [inches H2O]
- Metric units: [mbar]
Input:
Number with oating decimal point: 0.000...999999
Display: 10000.00 ft3/h
FULL SCALE VALUE
Set the low scale value for the high range transmitter analog input
signal.
The value entered here must be identical to the value set for the
owmeter.
Note:
• The units for differential pressure owmeters are
dependent on the system units selected for pressure:
- Imperial units [inches H2O]
- Metric units: [mbar]
Input:
Number with oating decimal point: 0.000...999999
Display: .000 ft3/h
LOW SCALE-HIGH RANGE
LOW SCALE
FULL SCALE
LOW SCALE-HI
RANGE
