ES749 Flow Computer
57
ll scale value for the high range transmitter analog input signal.
The value entered here must be identical to the value set for the
owmeter.
Note:
• The units for differential pressure owmeters are dependent
on the system units selected for pressure:
- Imperial units [inches H2O]
- Metric units: [mbar]
Input:
Number with oating decimal point: 0.000...999999
Display: 10000.00 ft3/h
FULL SCALE VALUE
Enter the value of delta P at which the unit will begin using the hi
range delta P pressure transmitter signal.
Input:
Number with oating decimal point: 0.000...999999
Display: 0.000 in H2O
SWITCH UP DP
Enter the value of delta P at which the unit will begin using the lo
range delta P pressure transmitter signal.
Input:
Number with oating decimal point: 0.000...999999
Display: 0.000 in H2O
SWITCH UP DP
Enter the low ow cutoff. This is used as a switchpoint for creep
suppression. This can be used to prevent low ows from being
registered.
Input:
Number with oating decimal point: 0.000...999999
Display: .000 ft3/h
LOW FLOW CUTOFF
6.8
FLOW INPUT
(Continued)
FLOW INPUT
FULL SCALE-HI
RANGE
SWITCH UP DP
SWITCH DOWN DP
LOW FLOW
CUTOFF
