ES749 Flow Computer
58
FLOW INPUT
6.8
FLOW INPUT
(Continued)
Enter the geometric ratio for the square law device being used. This
value is given by the manufacturer of the orice plate, or other square
law device.
Note:
"Beta" is only required for measuring gas or steam with some
square law owmeters.
Input:
Number with xed decimal point: 0.0000...1.0000
Display: 1.0000
ENTER BETA
ENTER BETA
CAL. DENSITY
Enter the calibration density. This is the uid density upon which the
owmeter's calibration is based.
Input:
Number with oating decimal point in requested units:
0.000...10.000
Display: 8.3372 (#/gal)
CAL. DENSITY
Enter the K-Factor of the owmeter.
Note:
• The K-Factor is expressed in pulses per unit volume (as
dened by "total units")
Input:
Number with oating decimal point: 0.001...999999
Display: .000 ft3/h
LOW FLOW CUTOFF
Enter the inlet pipe diameter or bore for the piping section upstream
of the ow measurement device.
Input:
Number with oating decimal point: 0.001...1000.00
Display: 4.090 in
INLET PIPE BORE
K-FACTOR
INLET PIPE BORE
To Next Page
