KN-4006 series UV Radiation Treatment System
9
Figure 2-1 KN-4006A/KN-4006B Figure 2-2 KN-4006AL/KN-4006L
Pic 2-3 Back effect
Figure 2-4 Right port Figure 2-5 Left port
Irradiation
device
Irradiation
device
Timer
control
circuit
Lamp pipe
fuse
Power socket
grounding
Power
COM
Timer
control
circuit
