KN-4006 series UV Radiation Treatment System
21
4.2 KN-4006AL/KN-4006BL Software operation
Operation panel
Figure 4-2 operation panel
Display interface
Figure 4-3 Display interface
LCD screen
Irradiation time
Status mark
UV output mark
System time
START
PAUSE /STOP
SET/OK
