How to install PIR Motion Detector
Mounting height
Motion Detector should be mounted
87inches(2.2m) above the floor.
Mount the bracket with the
included screws as shown to
the left. Then place the motion
detector in the bracket. Specify
the right direction of the detection
range of the motion sensor.
Test the operation of the motion
detector by putting it into testing
mode which is described at the
former page.
Detection Area
Side view
Special considerations
Don’t install PIR Motion Detector outdoors, in a garage and on glass.
PIR Motion Detector can’t detect motion through glass, like if someone’s moving outside a window.
Don’t install where PIR Motion Detector could get wet, like swing-out windows that could
be rained on.
Don’t install PIR Motion Detector within 3 feet (1 m) of a heat source like an electric heater, heat
vent or fireplace or another source that may produce turbulent air.
Don’t install PIR Motion Detector behind large appliances or furniture that may obstruct its
motion sensors.
GETTING STARTED
Install the SIM card
Important: A Micro-SIM card is required in order to use cellular
services when connecting to GSM/3G networks. Availability of
cellular capabilities depends on the wireless network.
