Keyscan Inc. A Member of the Kaba Group – CA8WL-AL Rev. B Installation Guide (07.15)
49
Table 8 – CA8WL-AL Quick Reference
Function
Location
Instructions/Notes
Additional
Reference
Power
PoE - Ethernet terminal
Maximum current load for all
devices = 680 mA
See page 26.
12 VDC – Power In (+) & (-)
terminals
See page 26
DIP Switches & Jumpers
J1 – Clear Memory
Resets board to factory defaults
See page 18.
S1.1 to S1.12 – System
Configuration
For communication and system
settings
See page 14.
S2.1 to S2.6
n/a
S2.7 to S2.8
n/a
S2.9 to S2.10 – System
Software Mode
Sets the board for the Keyscan
system software application
See page 17
J6 – System Reset
Resets the control board to affect
communication or jumper
changes
J8 to J9
n/a
J10 to J11
n/a
Communication
RS-232
For direct RS-232 serial
communication, connect to RS-
232 (TB5) terminal block
S1.10 & S1.11 – switches OFF
See page 21.
Ethernet - Operation Mode
(Network TCP/IP)
For network communication,
connect network cable to on-
board Ethernet terminal
S1.10 – switch ON / S1.11 –
switch OFF
See page 21.
Ethernet - Program Mode
(Network TCP/IP)
Ethernet program mode uses RS-
232 via TB5 at 9600 BPS.
S1.10 – Switch ON / S1.11 –
switch ON
RS-485
Connects to the PIM400-485 Unit
Communication Test
Voltages
See Table 3 on page
29.
Inputs & Outputs
TB3 & TB4
Disabled - do not function
Reader 1 & Reader 2
TB1 & TB2
Disabled – do not function
