Use the correct fuse
You must use a time delay 2-A fuse for 100- and 115-VAC inputs, and a time delay 1-A fuse for 230-VAC inputs:
Part Number Description Manufacturer Application
2110-1639 Fuse 1 A, 250 V Time-delay Littelfuse 230-V line voltage
2110-1640 Fuse 2 A, 250 V Time-delay 100- and 115-V line voltage
To configure the correct fuse, follow the three steps shown below:
Pull the fuse holder out of the
power supply.
Remove and insert the proper
fuse into the fuse holder.
Re-insert the fuse holder into the
power supply.
19
Keysight E36100B Series Operating and Service Guide
