Keysight Technologies E3644A User Manual

3 Remote Interface Reference
104 Keysight E364xA User’s and Service Guide
Power supply programming ranges
The SOURce subsystem requires parameters for programming values. The
available programming value for a parameter varies according to the desired
output range of the power supply. Table 3-1 lists the programming values
available and MINimum, MAXimum, DEFault and reset values of your power
supplies.
Refer to Table 3-1 and Table 3-2 to identify the programming values when
programming the power supply.
Table 3-1 Keysight E3640A/E3642A/E3644A programming ranges
E3640A E3642A E3644A
0 to 8V /3A
range
0 to 20 V/1.5 A
range
0 to 8 V/5 A
range
0 to 20 V/2.5 A
range
0 to 8 V/8 A
range
0 to 20 V/4 A
range
Voltage Programming
range
0 V to 8.24 V 0 V to 20.60 V 0 V to 8.24 V 0 V to 20.60 V 0 V to 8.24 V 0 V to 20.60 V
MAX value 8.24 V 20.60 V 8.24 V 20.60 V 8.24 V 20.60 V
MIN value0 V0 V0 V
DEFault value0 V0 V0 V
*RST value0 V0 V0 V
Current Programming
range
0 A to 3.09 A 0 A to 1.545 A 0 A to 5.15 A 0 A to 2.575 A 0 A to 8.24 A 0 A to 4.12 A
MAX value 3.09 A 1.545 A 5.15 A 2.575 A 8.24 A 4.12 A
MIN value0 A0 A0 A
DEFault value3 A1.5 A5 A2.5 A8 A 4 A
*RST value 3.00 A 5.00 A 8.00 A
