Keysight Technologies E3644A User Manual

7 Characteristic and Specifications
184 E364xA User’s and Service Guide
Electrical Specifications
Table 7-2 Electrical specifications
Parameters E3640A E3641A E3642A E3643A E3644A E3645A
Voltage output (V)
(at 0 to 40 °C)
Low range 0 to +8 V 0 to +35 V 0 to +8 V 0 to +35 V 0 to +8 V 0 to +35 V
High range 0 to +20 V 0 to +60 V 0 to +20 V 0 to +60 V 0 to +20 V 0 to +60 V
Current output (A)
(at 0 to 40 °C)
Low range 0 to 3 A 0 to 0.8 A 0 to 5 A 0 to 1.4 A 0 to 8 A 0 to 2.2 A
High range 0 to 1.5 A 0 to 0.5 A 0 to 2.5 A 0 to 0.8 A 0 to 4 A 0 to 1.3 A
Programming accuracy
[a]
12 months
(at 25 °C ±5 °C),
±(% of output + offset)
Voltage <0.05% + 10 mV
Current <0.2% + 10 mA
Readback accuracy
[a]
12 months (over GPIB and
RS-232 with respect to
actual output at
25 °C ±5 °C),
±(% of output + offset)
Voltage <0.05% + 5 mV
Current <0.15% + 5 mA
Meter accuracy
[a][b]
12 months (over front
panel with respect to
actual output at
25 °C ±5 °C),
±(% of output + offset)
Voltage < (0.05% + 2 counts)
Current <0.15% + 5 mA
Ripple and noise
(with outputs
ungrounded, or with
either output terminal
grounded, 20 Hz to
20 MHz)
Normal mode
voltage
<0.5 mVrms
and 5 mVpp
<1 mVrms
and 8 mVpp
<0.5 mVrms
and 5 mVpp
<1 mVrms
and 8 mVpp
<0.5 mVrms
and 5 mVpp
<1 mVrms
and 8 mVpp
Normal mode
current
<4 mArms
Common mode
current
<1.5 µArms
Load regulation
±(% of output + offset)
Voltage <0.01% + 3 mV
Current <0.01% + 250 µA

Keysight Technologies E3644A Specifications

General

Brand	Keysight Technologies
Model	E3644A
Category	Power Supply
Language	English
