Remote Interface Reference 3
Keysight E364xA User’s and Service Guide 137
Halting an Output in Progress
You can send a device clear at any time to stop an output in progress over the
GPIB interface. The status registers, the error queue, and all configuration states
are left unchanged when a device clear message is received. Device clear
performs the following actions.
– The power supply’s input and output buffers are cleared.
– The power supply is prepared to accept a new command string.
The following statement shows how to send a device clear over the GPIB interface
using Keysight BASIC.
The following statement shows how to send a device clear over the GPIB interface
using the GPIB Command Library for C or QuickBASIC.
CLEAR 705
IEEE-488 Device Clear
IOCLEAR (705)
– For RS-232 operation, sending the <Ctrl-C> character will perform the same
operation as the IEEE-488 device clear message. The power supply’s DTR
(data terminal ready) handshake line is set true following a device clear
message.
– All remote interface configurations can be entered only from the front panel.
Refer to “Configuring the Remote Interface” on page 63 to configure the GPIB
or RS-232 interface before operating the power supply remotely.
