Operation and Features 2
Keysight E364xA User’s and Service Guide 63
Configuring the Remote Interface
This power supply is shipped with both a GPIB (IEEE-488) interface and an
RS-232 interface. The GPIB interface is selected when the power supply is
shipped from the factory. Only one interface can be enabled at a time. To exit the
I/O configuration mode without any changes, press until the NO CHANGE
message is displayed.
– You can set the GPIB address, parity, and baud rate from the front panel only.
– The current selection is highlighted for emphasis. All other choices are
dimmed.
– The interface selection is stored in the non-volatile memory, and does not
change when power has been turned off or after a power-on reset (*RST
command).
GPIB configuration
1 Turn on the remote configuration mode.
If RS-232 appears, select GPIB / 488 by turning the knob.
2 Select the GPIB address.
You can set the power supply’s address to any value between 0 and 30. The
factory setting is address 5.
3 Save the change and exit the menu.
GPIB / 488
ADDR 05
SAVED
Your computer's GPIB interface card has its own address. Be sure to avoid using
the computer's address for any instrument on the interface bus. Keysight GPIB
interface cards generally use address 21.
