2Operation and Features
66 Keysight E364xA User’s and Service Guide
4 Save the operating state.
Recalling a stored state
1 Turn on the recall mode.
Memory location 1 will be displayed in the recall mode.
2 Select the stored operating state.
You can select the above RESET mode to reset the power supply to the
power-on state without turning power off/on or without using the *RST
command over the remote interface. Refer to “*RST” on page 117 for more
details on the *RST command.
3 Recall the stored operating state.
Remote interface operation
Use the following commands to store and recall the power supply state.
DONE
1: P15V_TEST
2:STATE2
RESET
DONE
*SAV {1|2|3|4|5} Store an operating state to a specified location.
*RCL {1|2|3|4|5} Recall a previously stored state from a specified
location.
MEM:STAT:NAME 1, ‘P15V_TEST’ Name the storage location 1 as “P15V_TEST”.
