3 Remote Interface Reference
124 Keysight E364xA User’s and Service Guide
7 Set the power supply to the middle (MID) calibration point.
8 Enter the reading you obtained from the DVM.
9 Set the power supply to the high (MAX) calibration point.
10 Enter the reading you obtained from the DVM.
11 Set the power supply to the overvoltage protection calibration point.
12 For current calibration, connect an appropriate current monitoring resistor
(shunt) across the output terminals and connect the DVM across the shunt
resistor.
13 Repeat steps 5 through 9 by substituting CURR for VOLT for current calibration.
For example, CAL:CURR:LEV MIN.
14 Record calibration information such as the next calibration due date or contact
person for future reference. The calibration string may contain up to 40
characters.
CAL:VOLT:LEV MID
CAL:VOLT:DATA 11.058
CAL:VOLT:LEV MAX
CAL:VOLT:DATA 21.566
CAL:VOLT:PROT
CALibration:STRing ‘<string>’
You should wait for the DVM reading to stabilize for accurate calibration.
