Items Description
11 Scope traces Voltage trace labels appear on the left side of the grid (V1 and V2) as shown in the display.
Current trace labels appear on the right side of the grid (I1 and I2).
Power trace labels appear on the center of the grid (P1 and P2).
Press Auto Scale to auto-scale the data traces.
12 Ground reference The ground reference of the trace. Ground references are offset so that they do not overlap. The
ground reference offset value is referenced to the horizontal center line of the grid.
13 Out of view arrows Indicate that the trace, P2 in the figure, is out of view. Press Knob Sc or Knob Ofs and use the Ver-
tical knob to bring the trace into view. Press Auto Scale to autoscale the data traces.
14 Horizontal reference Indicates the horizontal timebase reference. In the figure, the reference is centered. Change the ref-
erence justification in the Horizontal Settings field.
15 Trigger point indicator Shows the position of the trigger with respect to the waveform. In the figure, the trigger is offset to
the left of the original point. The trigger point corresponds to the timebase reference when the offset
is zero.
Menu Description
Scope Run Stop Run or stop data scope measurement.
Knob Scale or Ofs Set the function for the Vertical and Horizontal knob to adjust the vertical or horizontal waveform
display. Toggle between Scale (Sc) and Offset (Ofs) for each waveform settings. See Using knob in
scope view.
Sc, Ofs, or Mrk Marker (Mrk) only appear when Marker is enabled.
Selecting Mrk set the function of the Vertical and Horizontal knob to adjust the m1 and m2 marker
position. See Using knob in scope view.
Marker On or Off Enables or disables the Marker view.
Properties Sets the scope and waveform displays properties. See Scope properties and waveform settings.
Auto Scale Auto scales the traces on the display.
Keysight EL30000 Series User's Guide 119
