Programming Ranges
The following table shows the input ranges (voltage, current, power and resistance) and its default value that can be
programmed for each model in EL30000 Series.
Operating
Mode
Range EL33133A EL34143A EL34243A
CV High MAXimum 153 V 153 V Single/Parallel: 153 V
MINimum 0.02 V 0.015 V Single/Parallel: 0.015 V
Low MAXimum 15.3 V 15.3 V Single/Parallel: 15.3 V
MINimum 0.005 V 0.003 V Single/Parallel: 0.003 V
DEFault (*RST) 0.02 V 0.015 V Single/Parallel: 0.015 V
CC High MAXimum 40.8 A 61.2 A Single: 61.2 A
Parallel: 122.4 A
MINimum 0.01 A 0.012 A Single: 0.012 A
Parallel: 0.024 A
Medium MAXimum - 6.12 A Single: 6.12 A
Parallel: 12.24 A
MINimum - 0.002 A Single: 0.002 A
Parallel: 0.004 A
Low MAXimum 4.08 A 0.612 A Single: 0.612 A
Parallel: 1.224 A
MINimum 0.001 A 0.0002 A Single: 0.0002 A
Parallel: 0.0004 A
DEFault (*RST) 0.01 A 0.012 A 0.012 A
CP High MAXimum 255 W 357 W Single: 306 W
Parallel: 612 W
MINimum 1.5 W 2 W Single: 2 W
Parallel: 4 W
Medium MAXimum 25.5 W 35.7 W Single: 30.6 W
Parallel: 61.2 W
MINimum 0.15 W 0.3 W Single: 0.2 W
Parallel: 0.4 W
Low MAXimum 5.1 W 8.16 W Single: 7.14 W
Parallel: 14.28 W
MINimum 0.02 W 0.01 W Single: 0.01 W
Parallel: 0.02 W
DEFault (*RST) 1.5 W 2 W 2 W
Keysight EL30000 Series User's Guide 31
