Action: Folder creates a folder in the external memory.
Menu Description
Browse Allows you to browse and specify the location where the folder will be placed.
Folder Name Specifies the folder name. Use the virtual keyboard to enter your desired folder name.
Create Folder Creates a new folder in the specified location.
Recall Settings
The file you recall must be from the same instrument model.
Recall Settings allows you to browse to the state in the internal memory or browse to the state file (.csv format) in
the external memory to be recalled.
From: Int allows you to recall an instrument's state from the instrument's internal memory.
Menu Available settings Description
From: Int, Ext Selects whether you want to recall an instrument's state from the internal or external memory.
– Internal: The instrument's state is recalled from the instrument's internal memory.
– External: The instrument's state is recalled from the external USB drive.
Recall State 0 to State 9 Select the state number that you want to recall from.
Recall - Recall the state.
From: Ext allows you to recall an instrument's state from the external USB drive inserted in the front panel's USB
port.
Keysight EL30000 Series User's Guide 129
