Item Description
13 Intersect point
Shows where the measurement markers intersect the waveform.
14 Measurements
Shows the calculations of the waveform data between Marker 1 and Marker 2.
Dimension diagram
Setup the instrument
Place the instrument's feet on a flat, smooth horizontal surface. Connect input to the front panel or connect input
and sense leads to the rear panel, being careful not to short the leads together. Attach the power cable to the rear
panel, then plug it into main power. Connect LAN, USB, or GPIB cables as desired, and you may also secure the
instrument with a security lock cable.
Before disconnecting cables and cords from the instrument, turn the instrument off using the front-panel [Power]
key and disconnect from the supply source by unplugging the detachable power cord.
26
Keysight EL30000 Series User's Guide
