Operating
Mode
Range EL33133A EL34143A EL34243A
CR Ultra-High MAXimum - 100 kΩ Single: 100 kΩ
Parallel: 50 kΩ
MINimum - 250 Ω Single: 250 Ω
Parallel: 125 Ω
High MAXimum 4 kΩ 4000 Ω Single: 4000 Ω
Parallel: 2000 Ω
MINimum 100 Ω 100 Ω Single: 100 Ω
Parallel: 50 Ω
Medium MAXimum 1.25 kΩ 1250 Ω Single: 1250 Ω
Parallel: 625 Ω
MINimum 10 Ω 10 Ω Single: 10 Ω
Parallel: 5 Ω
Low MAXimum 30 Ω 30 Ω Single: 30 Ω
Parallel: 15 Ω
MINimum 0.08 Ω 0.05 Ω Single : 0.05 Ω
Parallel: 0.025 Ω
DEFault (*RST) 4 kΩ 100 kΩ 100 kΩ
32
