121
Keysight Handheld Analyzers
N99xxA User’s Guide
8 Calibration for NA, CAT, and VVM Modes
Calibration removes the systematic errors that are associated with
measurements in NA, CAT, and VVM Modes. Key presses are identical in all of
these Modes.
In this Chapter
“Why and When to Calibrate” on page 122
“Definitions” on page 122
“CalReady” on page 123
“How to Perform a Calibration” on page 123
“QuickCal (N991xA/2xA/3xA Only)” on page 125
“Mechanical Cal” on page 127
“ECal” on page 130
“Simple Response Cals ” on page 132
“View Cal” on page 134
“Calibration Type” on page 134
“Enhanced Response Optimization” on page 139
“Interpolation *” on page 140
“Cal ON ? – Questionable Accuracy” on page 140
“Compatible Mode Calibrations” on page 140
“Save the Calibration” on page 140
“CalReady Properties” on page 141
“Verify a Calibration” on page 142
“Test the Jumper Cable” on page 142
