550 Keysight N9927-90001 User’s Guide

Noise Figure Mode (Option 356 – CPU2 Only)

Using Noise Figure

Noise Figure enables you to do the following:

Select Noise Figure Mode before making any setting in this chapter.

How to select Noise Figure Mode:

—Press Mode_

—Then More

—Then Noise Figure

The FieldFox uses the Y-Factor technique to accurately verify and characterize the noise figure

of devices. Option 356 has these features:

Five Measurement Types

—Noise Figure

— Noise Factor

—Gain

— Noise Temperature

—Y-Factor

Four Measurement Setup Types

— Noise Source

—DUT

—Integration

—Uncertainty

Four Pre-configured DUT Measurement Types

—Amplifier

—Downconverter

— Upconverter

— Multi-Stage Converter

Uncertainty Contribution Values can be Customized for Your Device

— Jitter uncertainty

— ENR uncertainty

— Uncertainty bars

— Mismatch uncertainty

— User calibration uncertainty
