436 Keysight N9927-90001 User’s Guide
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
—Then Record Playback SetupThe following selections are available ONLY
when a session is NOT open.
—Then Storage Device
to select the media which stores the sessions to be
managed. This is a different setting from the Save/Recall Storage Device
setting.
— Then choose from the following:
— Internal
FieldFox memory (default)
— SD Card
An external SD Card (must be inserted)
— USB
An external USB flash drive (must be inserted)
—Then Manage Sessions
— Then choose from the following:
— Rename
Using the FieldFox labeler, change the name of the session.
AutoSession (n) is the default name where (n) is the next-available number.
Learn more in “How to use the FieldFox labeler ” on page 674.
— Sort
Arrange the listing of sessions by Name, by Date, or by Size.
— Delete
After a confirmation prompt, removes the contents of the
selected session from the list.
— Copy
Copies the selected session to a different storage device, or the
same storage device with ‘Copy(n)_’ appended to the beginning of
the name so that duplication is prevented.
— Copy All
Copies ALL of the listed sessions to a different storage
device, or the same storage device with ‘Copy(n)_’ appended to the
beginning of the names so that duplication is prevented.
— Delete All
Deletes ALL of the listed sessions.
Record Playback Example (SA Only)
The following “Interval Recording” example shows how you can record spectral
activity over a longer period of time with less trace storage.
—Press Trace 6
then, with Trace = 1, press State then Max Hold
—Then Record Playback
—Then New Session
—Then Recording Configuration
—Then Record Source to Trace1
—Then Record Interval
to 10 s (seconds).
—Then Back
—Then Recorder Player
