448 Keysight N9927-90001 User’s Guide
Built-in Power Meter Mode – Option 310
Built-in Power Meter Settings
Radio Standard
A Radio Standard can used to integrate power within specific radio channels.
When a Radio Standard is selected, the Span setting is automatically coupled
to the defined Channel Width for that standard. (Width is the same for all
channels within a standard.) Also, Unit is set to Chan, and CF is set to the
nearest specific Channel defined in the standard.
Learn more about Radio Standards, including Importing and Deleting Custom
Radio Standards, beginning in “Custom Radio Standards” on page 150
How to select a Radio Standard
—Press Measure 1 OR Freq/Dist
—Then Radio Standard
— Then select a standard using the arrows or rotary knob and press
Enter
.
Attenuation
The Attenuation setting controls the power level into the FieldFox.
To compare Built-in Power Meter Mode measurements to SA Channel Power
measurements, use the same attenuation settings. Built-in Power Meter Mode
defaults to 30 dB attenuation, while SA mode defaults to 10 dB attention. In
Built-in Power Meter, the attenuation setting is NOT annotated on the screen.
How to set Attenuation
—Press Scale/Amptd
—Then More
—Then RF Atten
— Then use the arrows or rotary knob to choose from either 30 dB or 10
dB
The following Built-in Power Meter settings are identical to the standard
Power Meter settings. To learn about these settings, please refer to the
following pages:
“Scale” on page 455
“Relative and Offset Power Measurements” on page 456
“Display Units” on page 456
“Averaging” on page 457
“Scale” on page 455
“Limits” on page 458
