354 Keysight N9927-90001 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
— Array Antenna: Center frequency, Azimuth Ref, and Elevation
Ref
— Polar Display: Ref
See also “How to Set Up Phased Array Antenna Settings” on
page 341.
d. Optional: Measure
> Data Logging:
i. Record Settings
then choose
ii. Measure Interval OFF ON
iii. Interval Type Time Distance
iv. Time Interval if applicable (only active when Interval Type =
Time) or
v. Distance Interval
if applicable (only active when Interval
Type = Distance)
vi. Auto Save OFF ON
vii.Back
to return to previous menu
e. Save Recall Rec-Playback
(Save Log File, Recall or
f. Record
or
g. Play
if you have a previously stored data scan
See also “How to Set Up Phased Array Antenna Settings” on
page 341.
h. Optional: Press Sweep 3
and modify/select items:
— Single
— Continuous OFF ON to ON (default)
— Restart
— Dwell Time For pulsed RF measurements, it is recommended
that the Dwell Time is increased to ~100 ms.
Default = 10 ms.
i. Optional: Press Sweep 3
and modify/select items:
— Single
— Continuous OFF ON to ON (default)
— Restart
