36 Keysight N9927-90001 User’s Guide
Preparing for Initial Use of Your New FieldFox
Take the FieldFox Tour
No. Caption Description Learn
More:
1 Power ON: press momentarily.
STAND BY: with FieldFox power ON, press briefly.
OFF: press and hold until the FieldFox shuts off (about 4 seconds).
“FieldFox
ON/OFF
Settings”
on
page 29
2 LED Not lit: FieldFox OFF, not charging
Green: FieldFox ON. Charging status indicated by battery icon on screen
Orange, flashing: FieldFox STAND BY
Orange, intensity increasing, flashing slowly: FieldFox OFF, charging
“Power
Button
LED
Status”
on
page 30
3
System
Displays a sub-menu for system setup “System
Settings”
on
page 623
4 Function keys
Includes: Freq/Dist, Scale/Amptd, BW, Sweep, Trace, Meas
Setup, Measure, and Mode.
Refer to
specific
Mode.
5
Preset
Returns the analyzer to a known state “How to
Preset the
FieldFox”
on
page 625
6
Enter
Confirms a parameter selection or configuration --
7
Marker
Activates marker function “All about
Markers”
on
page 598
8
Mkr-->Tools
Displays a sub-menu for marker functions “All about
Markers”
on
page 598
9
Esc
Exits and closes the Active Entry dialog box or clears the character input --
10
Save/Recall
Saves the current trace or recalls saved data from memory “Saving
and
Recalling
Files” on
page 672
