Getting Started Guide 53
Front and Rear Panel Functions
Rear Panel Features
Rear Panel Features
Figure 4-2 Slot numbers
The slot numbers for the different sections of the rear panel that are marked in
the illustration above; they are described in the following sections.
Do not cover or block the air flow vents. The test platform draws air in from the
left side and exhausts air from the right side.
The main power cord can be used as the system disconnecting device. It
disconnects the mains circuits from the mains supply.
