60 Getting Started Guide
Front and Rear Panel Functions
Rear Panel Features
Slots 11, 10: RFIO
Figure 4-9 UXM 5G Rear Panel -- RFIO Connectors
These connectors relate to the RFIO circuit board within the UXM 5G.
Name Description Notes
IF IN 3 SMA (Reserved for future use.)
IF IN 4 SMA (Reserved for future use.)
IF OUT 8 SMA (Reserved for future use.)
IF OUT 7 SMA (Reserved for future use.)
IF OUT 6 SMA (Reserved for future use.)
IF OUT 5 SMA (Reserved for future use.)
IF IN 1 SMA (Reserved for future use.)
IF IN 2 SMA (Reserved for future use.)
IF OUT 4 SMA (Reserved for future use.)
IF OUT 3 SMA (Reserved for future use.)
IF OUT 2 SMA (Reserved for future use.)
IF OUT 1 SMA (Reserved for future use.)
