4-38 Service Guide N5227-90001
Troubleshooting PNA Series Microwave Network Analyzers
Measurement System Troubleshooting N5227A
Equipment Used for These Tests
To determine which assembly is defective, check the signal at each available measurement point in the
signal path from the output of the source board to the output port.
Set the network analyzer for an S
11,
S
22,
S
33,
or S
44,
measurement for Port 1, 2, 3, or 4 respectively, with a CW
frequency of 800 MHz.
Perform the following checks in the order presented.
Checking the A29, A30, A31, and A32 Receiver Couplers
1. Locate the appropriate semirigid cable at the output of the receiver coupler to be checked:
Options 200 and 400
Port 1; W19 of A29
Port 2; W31 of A32
Port 3; W23 of A30
Port 4; W27 of A31
Options 219, 224, 419, and 423
Port 1; W81 of A29
Port 2; W93 of A32
Port 3; W85 of A30
Port 4; W89 of A31
2. Using a 5/16-inch torque wrench, disconnect the semirigid cable at the receiver coupler.
3. Connect the spectrum analyzer to the open receiver coupler connector. Set the spectrum analyzer to
measure a signal at 800 MHz.
4. If the 800 MHz signal is not present and the analyzer has mechanical switches, continue testing at
“Checking the A50, A51, A52, and A53 Mechanical Switches” on page 4-39.
5. If the 800 MHz signal is not present and the analyzer does not have mechanical switches, replace the
receiver coupler. Refer to “Removing and Replacing the A29 –A32 Receiver Couplers and Receiver
Coupler Mounting Brackets” on page 7-32.
6. If the 800 MHz signal is present and the analyzer has source attenuators and bias tees, reconnect the
cable to the receiver coupler and continue testing at “Checking the A38, A39, A40, and A41 60-dB Source
Step Attenuators” on page 4-39
7. If the 800 MHz signal is present and the analyzer does not have source attenuators and bias tees, replace
the test port coupler. Refer to “Removing and Replacing the A33–A36 Test Port Couplers” on page 7-34.
Equipment Type
Model or
Part Number
Alternate Model or Part
Number
Spectrum analyzer 8565E
856xE
a
a. Must be capable of measuring a signal at 1 GHz.
