Service Guide N5227-90001 6-9
PNA Series Microwave Network Analyzers Replaceable Parts
N5227A Replaceable Parts Listings
Front Panel Assembly, Front Side, All Options
NOTE The N5245-60024 (Was N5247-60004) 2-port front panel assembly and the N5245-60022
(Was N5247-60005) 4-port front panel assembly contain the items shown in the following
table.
Reference
Designator
Part Number Qty Description
➀
N5247-20137
Was N5247-60026,
or N5247-60004
1
Front frame, 2-port (frame only, not the assembly)
N5247-20141
Was N5247-60027,
or N5247-60005
Front frame, 4-port (frame only, not the assembly)
8160-0660 1.2 m
RFI gasket material, 1.2 meters in length
(Must be ordered separately from front frame.)
➁
0515-2044 -- Machine screw, M4.0 x 12 flat head (To attach front frame to chassis.)
➂
a
a. Refer to “Rack Mount Kits and Handle Kits” on page 6-83 for part numbers of complete rack mount and handle
kits.
5041-9691
2
Trim strip
➃
N5242-80005 1 Keypad overlay
➄
N5227-80010
Was N5227-80008
1
Front panel overlay, 2-port (Option 200)
N5227-80009 Front panel overlay, 2-port (Option 201)
N5227-80012
Was N5227-80002
Front panel overlay, 2-port (Option 210)
N5227-80009 Front panel overlay, 2-port (Option 219)
N5227-80011
Was N5227-80004
Front panel overlay, 4-port (Option 400)
N5227-80005 Front panel overlay, 4-port (Option 401)
N5227-80013
Was N5227-80003
Front panel overlay, 4-port (Option 410)
N5227-80014
Was N5227-80005
Front panel overlay, 4-port (Option 419)
➅
N5242-80007 1 Power switch overlay
➆
W1312-40017 1 Front (RPG) knob
➇
N5227-80001
1
Nameplate, N5227A
➈
0515-1946 2/4
Machine screw, M3.0 x 6, 90-deg flat head (To attach subpanel to front
frame.) (Only 2 used on 2-port, all 4 used on 4-port.)
Not shown
5023-1399
2
Front handle
