Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5227A
Table 6-2 Par t Number Li sting by Ty pe o f Part
Assemblies and Cables
• “Front Panel Assembly, Front Side, All Options” on page 6-9
• “Front Panel Assembly, Back Side, All Options” on page 6-11
• Top Assemblies and Cables, All Options:
❏ “Top Assemblies, All Options” on page 6-16
❏ “Top Cables, All Cables—All Options” on page 6-18
• Bottom Assemblies and Cables by Option Set:
❏ “2-Port Configuration, Option 200” on page 6-20
❏ “2-Port Configuration, Option 201” on page 6-26
❏ “2-Port Configuration, Option 210” on page 6-32
❏ “2-Port Configuration, Option 219” on page 6-38
❏ “4-Port Configuration, Option 400” on page 6-44
❏ “4-Port Configuration, Option 401” on page 6-50
❏ “4-Port Configuration, Option 410” on page 6-56
❏ “4-Port Configuration, Option 419” on page 6-62
• “Rear-panel Assembly, All Options” on page 6-70
Hardware
• “Fan Assemblies, All Options” on page 6-72
• “Top Hardware and Miscellaneous Parts, All Options” on page 6-74
• “Bottom Hardware and Miscellaneous Parts” on page 6-76
• “Internal Hardware and Miscellaneous Parts, All Options” on page 6-78
• “External Hardware and Miscellaneous Parts, All Options” on page 6-80
Miscellaneous
• Service Tools on page 6-82
• Documentation on page 6-82
• GPIB Cables/GPIB Adapter on page 6-82
• Fuses on page 6-82
• Battery on page 6-82
• Protective Guards for Front Panel Jumpers on page 6-82
• USB Accessories on page 6-83
• ESD Supplies on page 6-83
• Rack Mount Kits and Handle Kits on page 6-83
