6-40 Service Guide N5227-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5227A
Bottom RF Cables, Option 219
Reference
Designator
Typ e
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable
Part Number Qty Description
W12 SR N5247-20059 1 A60 port 1 70 GHz doubler to W11
W14 SR N5247-20072 1 A60 port 1 70 GHz doubler to W13
W24 SR N5247-20061 1 A63 port 2 70 GHz doubler to W23
W26 SR N5247-20051 1 A63 port 2 70 GHz doubler to W25
W27 SR N5247-20044 1 A60 port 1 70 GHz doubler to A29 port 1 receiver coupler
W30 SR N5247-20043 1 A63 port 2 70 GHz doubler to A32 port 2 receiver coupler
W33 SR N5247-20079 1 A29 port 1 receiver coupler to A37 reference mixer switch
W34 SR N5247-20039 1 A33 port 1 coupler to front-panel REF 1 CPLR ARM
W45 SR N5247-20058 1 A32 port 2 receiver coupler to front-panel REF 2 SOURCE OUT
W46 SR N5247-20041 1 A36 port 2 coupler to front-panel port 2 CPLR ARM
W51 SR N5247-20011 1 F
ront-panel REF 1 SOURCE OUT
to A37 ref mixer switch
W52 SR N5247-20012 1 REF 1 RCVR R1 IN to A37 reference mixer switch
W53 SR N5247-20048 1 A37 reference mixer switch to A27 mixer brick (R1)
W56 SR N5247-20045 1 A27 mixer brick (R2) to
front-panel REF 2 RCVR R2 IN
W60 SR N5247-20107 6 Front-panel jumper
W61 SR Refer to “Top Cables, All Cables—All Options” on page 6-18.
W66 SR N5247-20109 1 W65 to rear-panel EXT TSET DRIVE RF OUT (J6)
W69 SR N5247-20112 1 A27 mix brick to rear-panel EXT TSET DRIVE LO OUT (J5)
W62 SR N5247-20100 1 A25 HMA26.5 to A27 mixer brick
W71 F N5242-60017 1 A27 mixer brick (A) to A24 IF multiplexer (P1)
W72 F N5242-60025 1 A27 mixer brick (R1) to A24 IF multiplexer (P601)
W73 F N5242-60026 1 A27 mixer brick (R2) to A24 IF multiplexer (P801)
W74 F N5242-60018 1 A27 mixer brick (B) to A24 IF multiplexer (P201)
W79 - 83,
W91- 92,
W97- 98
FRefer to “Top Cables, All Cables—All Options” on page 6-18.
W101 SR N5247-20083 1 A29 port 1 receiver coupler to A38 port 1 source attenuator
W102 SR N5247-20014 1
A38 port 1 source attenuator to front-panel port 1 SOURCE OUT
W103 SR N5247-20081 1 Front-panel port 1 CPLR THRU to A42 port 1 bias tee
W104 SR N5247-20040 1 A33 port 1 coupler to A42 port 1 bias tee
W113 SR N5247-20083 1 A32 port 2 receiver coupler to A41 port 2 source attenuator
W114 SR N5247-20034 1
A41 port 2 source attenuator to front-panel port 2 SOURCE OUT
W115 SR N5247-20027 1 Front-panel port 2 CPLR THRU to A45 port 2 bias tee
W116 SR N5247-20042 1 A36 port 2 coupler to A45 port 2 bias tee
W117 SR N5247-20013 1 Front-panel port 1 RCVR A IN to A46 port 1 receiver attenuator
W118 SR N5247-20047 1 A46 port 1 receiver attenuator to A27 mixer brick (A)
W123 SR N5247-20020 1 Port 2 RCVR B IN to A49 port 2 receiver attenuator
W124 SR N5247-20046 1 A49 port 2 receiver attenuator to A27 mixer brick (B)
