6-66 Service Guide N5227-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5227A
Bottom RF Cables, Option 419 (Ports 3 and 4)
Reference
Designator
Typ e
a
a. SR = semirigid coaxial cable; F = flexible coaxial cable
Part Number Qty Description
W16 SR N5247-20060 1 A61 port 3 70 GHZ doubler to W15
W18 SR N5247-20084 1 A61 port 3 70 GHZ doubler to W17
W20 SR N5247-20015 1 A62 port 4 70 GHZ doubler to W19
W22 SR N5247-20068 1 A62 port 4 70 GHZ doubler to W21
W28 SR N5247-20043 1 A61 port 3 70 GHz doubler to A30 port 3 receiver coupler
W29 SR N5247-20044 1 A62 port 4 70 GHz doubler to A31 port 4 receiver coupler
W37 SR N5247-20070 1 A30 port 3 receiver coupler to front-panel REF 3 SOURCE OUT
W38 SR N5247-20007 1 A34 port 3 coupler to front-panel port 3 CPLR ARM
W41 SR N5247-20069 1 A31 port 4 receiver coupler to front-panel REF 4 SOURCE OUT
W42 SR N5247-20026 1 A35 port 4 coupler to front-panel port 4 CPLR ARM
W54 SR N5247-20062 1 REF 3 RCVR R3 IN to A28 mixer brick (R3)
W55 SR N5247-20067 1 REF 4 RCVR R4 IN to A69 A69 3 dB pad on A28 mixer brick (R4)
W58 -- N5247-20138 1 2.4 mm cap for A28 mixer brick
W64 SR N5245-20022 1 A26 splitter to A28 mixer brick
W68 SR N5247-20088 1 Rear-panel port RF2 OUT (J12) to W67
W75 F N5242-60024 1 A28 mixer brick (D) to A24 IF multiplexer (P801)
W76 F N5242-60019 1 A28 m mixer brick (R4) to A24 IF multiplexer (P414)
W77 F N5242-60020 1 A28 mixer brick (R3) to A24 IF multiplexer (P413)
W78 F N5242-60023 1 A28 mixer brick (C) to A24 IF multiplexer (P601)
W80, 82,
W93 - 96
F Refer to “Top Cables, All Cables—All Options” on page 6-18.
W105 SR N5247-20083 1 A30 port 3 receiver coupler to A39 port 3 source attenuator
W106 SR N5247-20009 1
A39 port 3 source attenuator to front-panel port 3 SOURCE OUT
W107 SR N5247-20010 1 Port 3 CPLR THRU to A43 port 3 bias tee
W108 SR N5247-20028 1 A43 port 3 bias tee to A34 port 3 coupler
W109 SR N5247-20083 1 A31 port 4 receiver coupler to A40 port 4 source attenuator
W110 SR N5247-20025 1
A40 port 4 source attenuator to front-panel port 4 SOURCE OUT
W111 SR N5247-20021 1 Port 4 CPLR THRU to A44 port 4 bias tee
W112 SR N5247-20029 1 A44 port 4 bias tee to A35 port 4 coupler
W119 SR N5247-20008 1 Port 3 RCVR C IN to A47 port 3 receiver attenuator
W120 SR N5247-20064 1 A47 port 3 receiver attenuator to A28 mixer brick (C)
W121 SR N5247-20024 1 Port 4 RCVR D IN to A48 port 4 receiver attenuator
W122 SR N5247-20065 1 A48 port 4 receiver attenuator to A28 mixer brick (D)
