Service Guide N5227-90001 6-77
PNA Series Microwave Network Analyzers Replaceable Parts
N5227A Replaceable Parts Listings
Figure 6-36 Bottom Hardware and Miscellaneous Parts
Not shown
0515-0669 -- Machine screw, M4.0 x 0.7, pan head (To attach A24 IF MUX to test set deck.)
N5242-00019 1
Stabilizer bracket (Between A23 test set motherboard and A24 IF mux board.)
N5247-00017 1 Cross bracket on test set deck
Ref Desig
Part Number
Qty
Description
