Wire Size Metric size(Note1) Resistance Max length to limitvoltage to 1 V/lead
for 5 A for 10 A for 20 A for 50 A
AWG 2 wires bundled 4 wires bundled Ω per foot Wire length in feext
20 7.8 6.9 0.0102
20 x x x
18 14.5 12.8 0.0064
30 15 x x
16 18.2 16.1 0.0040
50 25 x x
14 29.3 25.9 0.0025
80 40 20 x
12 37.6 33.2 0.0016
125 63 30 x
10 51.7 45.7 0.0010
200 100 50 20
8 70.5 62.3 0.0006
320 160 80 32
6 94 83 0.0004
504 252 126 50
Area in mm
2
2 wires bundled 4 wires bundled Ω per meter Wire length in meters
0.5 7.8 6.9 0.0401
5 x x x
0.75 9.4 8.3 0.0267
7.4 x x x
1 12.7 11.2 0.0200
10 5 x x
1.5 15.0 13.3 0.0137
14.6 7.2 x x
2.5 23.5 20.8 0.0082
24.4 12.2 6.1 x
4 30.1 26.6 0.0051
39.2 19.6 9.8 3.9
6 37.6 33.2 0.0034
58 29 14.7 5.9
10 59.2 52.3 0.0020
102 51 25 10.3
Notes:
1. Capacity for AWG wires derived from MIL-W-5088B. Maximum ambient temperature: 55°C.
Maximum wire temperature: 105°C.
2. Capacity for metric wires are derived from IE Publication 335-1.
3. Capacity of aluminum wire is approximately 84% of that listed for copper wire.
4. “x” indicates wire is not rated for the maximum output current of the power module.
5. Because of wire inductance considerations, it is also recommended that you keep your load leads
twisted, tie wrapped, or bundled together and less than 50 feet (14.7 meters) in length per lead.
Keysight N6700C Operating and Service Guide 59
2 Installation
