Keysight PNA Series User Manual

REF 2
RCVR R2 IN SOURCE OUT
PORT 2
RCVR B IN CPLR ARM
SOURCE OUTCPLR THRU
+15 dBm +30 dBm
+30 dBm +20 dBm
+15 dBm +15 dBm
REF 1
SOURCE OUT
RCVR R1 IN
PORT 1
CPLR ARM RCVR A IN
CPLR THRUSOURCE OUT
+15 dBm
+30 dBm
+30 dBm
+30 dBm
+15 dBm
+15 dBm
0.1 dB compression level:
–5 dBm typical at 26.5 GHz
PNA-X N5242A Network Analyzer
Figure 21. PNA-X N5242A network analyzer front panel connectors.
PNA N5222A Network AnalyzerPNA-L N523xA Network Analyzer
37 | Keysight | Antenna Test – Selection Guide

Keysight PNA Series Specifications

General

Number of Ports	2, 4
Impedance	50 Ω
Output Power Range	-55 dBm to +13 dBm (varies by model)
Dimensions	Varies by model
Weight	Varies by model
Power Requirements	100-240 VAC, 50/60 Hz
Storage Temperature	-40°C to 70°C
