Kia Rio 2021 - Engine Compartment

Maintenance
47
ENGINE COMPARTMENT
OSC078047N
■■
Smartstream G1.6
❈ The actual engine compartment in the vehicle may differ from the illustration.
1. Engine coolant reservoir
2. Engine oil filler cap
3. Brake / clutch fluid reservoir
4. Air cleaner
5. Fuse box
6. Negative battery terminal
7. Positive battery terminal
8. Engine oil dipstick
9. Radiator cap
10. Windshield washer fluid reservoir
